Measurement and Test Stand Technology
Precision in Measurement and Test Stand Technology
In the fields of test stand, measurement, and sensor technology, the highest levels of accuracy, performance, and flexibility are essential. Requirements for components and processes are becoming increasingly complex and demanding.
Custom-made solutions are part of our standard offering
Drawing on years of expertise, we develop and supply products—starting from a batch size of just one—that are optimally tailored to a wide range of challenges, ensuring precise testing and measurement results.
Backlash-free Torque Transmission and Misalignment Compensation in Test Stands
Safety couplings reliably protect sensitive measuring units—such as torque sensors or test specimens—from overloads, preventing costly damage and reducing the need for repairs and downtime. Thanks to their high torsional rigidity, torsionally stiff metal bellows
couplings ensure precise angular transmission and are ideally suited for connection to torque transducers or encoders. Vibration-damping elastomer couplings, available in various Shore hardness grades, allow for flexible adjustment of damping characteristics.
JAKOB offers high-speed versions of servo, safety, and distance couplings, designed for maximum rotational speeds, excellent smooth running, and minimal mass inertia. Precision balancing and innovative solutions, such as the Simple-Flex coupling, ensure peak performance in every application.
Clamping Force Measurement
The HMD series of hydraulic force transducers are robust instruments for measuring axial compressive forces; they provide a simple, cost-effective way to safely measure static and dynamic forces across a wide range of mechanical engineering applications.
Vacuum Technology for Precise Analysis
In ultra-high vacuum applications, JAKOB zeolite traps protect sensitive measuring instruments from vacuum pump oil vapors, thereby ensuring both precise analysis results and a long service life for the equipment.
JAKOB – Technology for Measurement and Testing Precision
Typical areas of use & applications:
- Test stands, e.g., for engines, transmissions, components, materials, or climate testing
- General test stand technology and construction
- Automated testing systems
- Connections / overload protection: torque sensors, torque transducers, measuring flanges, or test specimens
- Sensor technology / pulse generators / potentiometers
- Positioning units
- Measurement and control systems
Our Product Portfolio for Measurement and Test Stand Technology
Bellows Couplings
- backlash-free – torsionally rigid – highest precision
- high speeds – low moments of inertia
- for highly dynamic servo drives / reversing operation
- for precise, repeatable positioning
Elastomer Couplings
- backlash-free – precise torque transmission
- robust – vibration-damping – smooth running
- electrically insulating
- plug-in – easy to install – blind assembly
Miniature Couplings
- compact – high power density – wide range of variants
- torsionally rigid metal bellows couplings
- vibration-damping elastomer couplings
- highly compensating Oldham couplings
Distance Couplings
- backlash-free – variable lengths up to 6 m
- no additional intermediate supports required
- high rotational speeds – low mass moments of inertia
- torsionally rigid or vibration-damping
Safety Couplings
- torque-limiting – adjustable – backlash-free
- for protection against collision and overload damage
- for maximum productivity and efficiency
- wide range of variants – for direct and indirect drives
Stainless Steel Servocouplings
- robust – corrosion-resistant – hygienic
- temperatures from -40°C to +350°C
- backlash-free – versatile – easy to install
- torsionally rigid or vibration-damping
Hydraulic Force Measuring System
- for measuring axial compressive forces
- self-powered measuring system – requires no external power
- multi-piston system – compensates for flatness and angular errors
- heat-treated steel – robust – corrosion-resistant
Vacuum Technology
- Vacuum components (ISO-KF, ISO-K, and ISO-CF)
- Vacuum valves
- Vacuum pump accessories
- Vacuum-related services
